Ride Over Obstacles
Class-leading 27 cm ground clearance and durable 25" tyres enable you to confidently overcome obstacles on the trail.
Charge Your Phone
Keep your phone and other devices charged so you can stay connected with an in-dash USB port (available on Premium models).
Nimble Steering
Navigate tight turns in the trail with ease thanks to electronic power steering (EPS), which lessens the effort required to turn.
Smooth Ride
Class-leading 22 cm front / 25 cm rear suspension travel offers a smooth, comfortable ride over tough terrain for all-day ride comfort.
Enhanced Vehicle Protection
Get added protection with an available full underbody skid plate and full-coverage front bumper. Plus, mud guards prevent debris collection under the cab.
Quieter Ride
Sealed suspension bushings prevent mud, dirt and water from entering, ensuring your machine runs quietly without routine maintenance.
Confident Starts
A 575 cca battery, 66-W stator and Polaris PULSE electrical system deliver enhanced charging, more confident starting, and the ability to easily run more accessories for added work and play capability.
Maximize Every Load
Connect your trailer to your RANGER SP 570 HD with the standard 2” hitch receiver to take advantage of the 680 kg towing capacity.
Haul More Cargo
The 226kg gas-assist dump box makes unloading heavy loads quick and easy.
Easy on the Lawn
For work around the house, engage Turf Mode to unlock the rear differential for easier and tighter turns that are easy on your lawn.
Instant Traction
On-demand AWD provides power to all four wheels when traction loss is detected for instant traction in rocky, wet and muddy terrain.
Technical Specifications
Cooling
Liquid
Cylinders-Displacement (cc)
567 cc
Drive System Type
On-Demand True AWD/2WD/ VersaTrac Turf Mode. Active Descent Control (ADC) and Heavy Duty features including upgraded rear driveshaft, grease nipples, HD sway bar, sealed suspensions bushings, sealed ball joints and driveshaft spline seals
Motor
4-stroke single cylinder DOHC
Fuel System/Battery
Electronic Fuel Injection
Engine Braking System
Yes
Horsepower
44 HP
Torque
48.8 Nm
Transmission / Final Drive
Automatic PVT H/L/N/R/P, shaft
Front Suspension
MacPherson Strut 22.9 cm Travel
Rear Suspension
Dual A-arm, 25.4 cm travel
Front/Rear Brakes
4-Wheel Hydraulic Disc
Parking Brake
Park in-transmission
Front Tyres
25 x 8-12, Carlisle 489
Rear Tyres
25 x 10-12, Carlisle 489
Wheels
Aluminium Black Xcelerator
Bed Box Dimensions (L x W x H)
84.6 x 123.7 x 31.2 cm
Front / Rear Rack or Box Capacity
226.8 kg
Estimated Dry Weight
529 kg
Fuel Capacity
35.9 L
Ground Clearance
27.9 cm
Hitch Towing Rating
680 kg
Hitch Type
Standard 5 cm receiver
Overall Vehicle Size (L x W x H)
274.3 x 142.2 x 188 cm
Payload capacity
454 kg
Person Capacity
2
Wheelbase
185.4 cm
Driver Instrumentation
4" LCD rider information centre: user-selectable blue/red backlighting and brightness, programmable service intervals, speedometer, tachometer, odometer, tripmeter, clock, hour meter, gear indicator, fuel gauge, coolant temperature, voltmeter, service indicator and codes, seat belt reminder
GET MORE DONE. HAVE MORE FUN. RANGER SP 570 HD delivers class-leading capability for work and a smooth ride for play.
