2026 KX85 L

Powered by a proven 84 cc engine combined with a chassis designed to maximise engine performance, the KX85 motorcycle is engineered to give young racers a competitive edge. With factory-inspired components and a choice of wheel sizes to accommodate a wider range of riders, these serious race machines help carve the path to the podium.

FEATURING:

  • 84 cc LIQUID-COOLED, 2-STROKE SINGLE-CYLINDER ENGINE
  • NEW KYB ø43 mm INVERTED FRONT FORK AND UNI TRAK REAR SUSPENSION
  • NEW RIGID PERIMETER FRAME
  • NEW LARGE ø240 mm FRONT, ø220 mm REAR DISC BRAKES
  • UPDATED FACTORY-INSPIRED KX STYLING

ADDITIONAL VEHICLE FEATURES:

  • NEW aluminium Renthal Fatbar handlebar with ODI Lock-On grips
  • NEW ERGO-FIT adjustable 8-position handlebar mount
  • NEW Larger riding triangle and wider handlebar and footpegs
  • NEW Increased rear wheel travel on par with full-size KX models
  • 19” front wheel and 16” rear wheel
  • NEW Dunlop Geomax MX34 tyres

MAKE AN ENQUIRY

Features

REAL CHASSIS PERFORMANCE

Inspired by Full-Size KX Motocrossers

A robust perimeter frame delivers the strength and torsional rigidity needed to harness the engine’s full power, giving riders the confidence to push hard on the track. Complementing the frame are new high-rigidity front forks and a long-stroke rear suspension, along with a powerful braking system. Built with the same “Built to Win” spirit that defines the full-size KX models, the new machine is engineered to give young racers a competitive edge.

THE RIGHT FIT

Sized Right for You

Feeling at one with your machine is extremely important for speed and control – especially for aspiring racers learning how to get the most from themselves and their bikes.
For 2026, the KX85 and KX85 L offer a roomier rider triangle, wider handlebar, greater ERGO-FIT adjustability, and a host of high-grade, big-bike-style ergonomic components designed for enhanced control and comfort.

ENGINE

Proven Performance

Designed to deliver both ample power across the rev range and strong top-end performance, the 84 cc 2-stroke single-cylinder engine offers winning potential in a highly competitive class. The high-performance engine produces crisp, responsive power and offers proven durability to finish each ride with confidence. A close ratio six-speed transmission and manual clutch allow aspiring racers to hone their shifting skills and get maximum performance out of the KX85 motorcycle.

Technical Specifications

Engine
2-stroke Single with KIPS
Displacement
84 cc
Bore x Stroke
48.5 x 45.8 mm
Compression Ratio
10.9:1 (low speed), 9.0:1 (high speed)
Induction
Piston reed valve
Fuel System
Carburettor: Keihin PWK28
Ignition
Digital-CDI
Starting
Primary kick
Cooling
Liquid-cooled
Lubrication
Pre-mix (32:1)
Transmission
6-speed, return
Primary Reduction Ratio
3.400 (68/20)
Gear Ratio 1st
2.538 (33/13)
Gear Ratio 2nd
1.875 (30/16)
Gear Ratio 3rd
1.500 (27/18)
Gear Ratio 4th
1.250 (25/20)
Gear Ratio 5th
1.090 (24/22)
Gear Ratio 6th
0.956 (22/23)
Final Reduction Ratio
3.923 (51/13)
Clutch
Wet multi-disc, manual
Final Drive
Chain
Frame
Perimeter, high-tensile steel
Front Suspension
ø43 mm inverted fork with adjustable compression and rebound damping
Rear Suspension
Uni Trak, single shock with adjustable dual-range (high/low-speed) compression damping, adjustable rebound damping and adjustable spring preload
Front Wheel Travel
275 mm
Rear Wheel Travel
305 mm
Rake
29.2°
Trail
117 mm
Steering Angle (L/R)
39° / 39°
Front Tyre
70/100-19 42M
Rear Tyre
90/100-16 51M
Front Brake/s
ø240 mm petal disc
Front Caliper/s
Dual-piston
Rear Brake
ø220 mm petal disc
Rear Caliper
Single-piston
ERGO-FIT
Yes
Dimensions (LxWxH)
1,935 x 800 x 1,165 mm
Wheelbase
1,310 mm
Road Clearance
330 mm
Seat Height
865 mm
Curb Weight*
78.2 kg
Weight without Fuel
74.6 kg
Fuel Capacity
5.0 litres
Model Code
KX85FTFNN
