Wonder. Engineered.
Wonder, the immediate and most intense sensation one has when looking at and riding this magnificent creation.
A magical and irrational wonder, engineered thanks to incredible Ducati brilliance and dedication. In the epic saga of Ducati superbikes, the new Panigale V4 represents the seventh generation, a synthesis of design and technology.
The aerodynamics package and appendages evolves towards a total aerodynamic redesign to achieve maximum integration of the aesthetic and aerodynamic function. Work that has seen designers and Ducati Corse technicians come together to develop solutions that ensure less roll resistance, while maintaining high vertical load.
Designed around the rider.
The main changes regard the contact points between motorcycle and rider and the position in the saddle. Tank, footpegs and seat fit area have been completely revised with the aim of heightening control in the most important phases of track riding and allowing the rider to fully exploit the performance of the Panigale V4 both over a single lap and during an extended session.
Mission racetrack.
Based on Ducati Corse experience, the chassis layout aims to improve track performance, or rather faster lap times that are achieved with less effort and can be more consistently replicated by both amateurs and professionals. Thanks to solutions such as the Ducati Hollow Symmetrical Swingarm and Front Frame with reduced lateral stiffness, the new Panigale V4 is quicker through the most delicate phases of track riding.
Technological re-evolution.
The electronic solutions integrated into the new Panigale V4 offer the rider an even more safe and sophisticated superbike that can amplify the riding ability of every rider.
The heart of performance.
The new Panigale V4 is powered by the latest generation Desmosedici Stradale. The MotoGP-derived engine evolves to conform with strict Euro 5+ standards and noise thresholds, achieving 216 hp of maximum power and dropping 1 kg in weight.
Expand the limits of customisation.
Ducati allows each rider to customise their Panigale V4. Riders can pick from a range of Ducati Performance accessories to enhance performance, aesthetics, and versatility. And by joining the exclusive Ducati Unica customisation programme, a rider can live the dream of creating their very own V4.
Aluminium alloy "Front Frame" with optimised stiffnesses
Front suspension
Fully adjustable Showa BPF fork, 43 mm chromed inner tubes
Front Wheel
5-spokes light alloy 3.50" x 17"
Front Tyre
Pirelli Diablo Supercorsa SP-V4 120/70 ZR17
Rear suspension
Fully adjustable Sachs unit. Aluminium Hollow Symmetrical Swingarm
Rear Wheel
5-spokes light alloy 6.00” x 17”
Rear Tyre
Pirelli Diablo Supercorsa SP-V4 200/60 ZR17
Wheel Travel (Front/Rear)
125 mm (4.9 in) - 130 mm (5.1 in)
Front Brake
2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Hypure® 4-piston calipers with Race eCBS. Self bleeding master cylinder.
Rear Brake
245 mm disc, 2-piston caliper with Race eCBS
Instrumentation
Digital unit with 6,9" TFT display and Optical Bonding, 1,280 x 480 px resolution
Wet weight no fuel
191 kg (421 lb)
Seat Height
850 mm (33.5 in)
Wheelbase
1,485 mm (58.5 in)
Rake
24°
Trail
98 mm (3.86 in)
Fuel Tank Capacity
17 l - 4.49 gallon (US)
Number of Seats
Single seat Two seats, if passenger seat kit accessory is mounted
Safety Equipment
Riding Modes, Power Modes, Race eCBS, Ducati Vehicle Observer (DVO), Ducati Traction Control (DTC) DVO, Ducati Wheelie Control (DWC) DVO, Ducati Slide Control (DSC), Engine Brake Control (EBC), Ducati Brake Light (DBL), Chain guard
Standard Equipment
Ducati Power Launch (DPL) DVO, Ducati Quick Shift (DQS) up/down 2.0, Full LED headlights with Daytime Running Light (DRL), Sachs steering damper, Quick adjustment buttons, Pit Limiter, Auto-off indicators
Ready for
Ducati Data Logger (DDL), Anti-Theft, Cruise Control, Tyre Pressure Monitoring System (TPMS), USB port*, Ducati Multimedia System (DMS)*, "Turn By Turn" navigator* *: Please refer to your local dealer for availability
Warranty
24 months unlimited mileage
Valve Clearance Check
24,000 km (15,000 miles)
Annual Service
12 months
Oil Service
12,000 km (7,500 miles) / 24 months
Notes
Bike specifications and equipment may vary from market to market. Please refer to your local dealer for further information
Wonder. Engineered.
Wonder, the immediate and most intense sensation one has when looking at and riding this magnificent creation.
A magical and irrational wonder, engineered thanks to incredible Ducati brilliance and dedication. In the epic saga of Ducati superbikes, the new Panigale V4 represents the seventh generation, a synthesis of design and technology.
content_description2
Engine;Transmission;Chassis;Dimensions And Weights;Equipment;Warranty;Emissions And Consumption
#####Type|Desmosedici Stradale 90° V4, counter-rotating crankshaft, Desmodromic timing, 4 valves per cylinder, liquid-cooled;Displacement|1,103 cc;Bore x Stroke|81 x 53.5 mm;Compression Ratio|14:1;Power|158.9 kW (216 hp) @ 13,500 rpm;Torque|120.9 Nm (89.2 lb-ft) @ 11,250 rpm;Fuel Injection|Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies. Variable length intake system;Exhaust|4-2-1-2 system, with 2 catalytic converters and 4 lambda probes
#####Gearbox|6 speed with Ducati Quick Shift (DQS) up/down 2.0;Primary drive|Straight cut gears, Ratio 1.80:1;Ratio|1=36/15 2=34/17 3=33/19 4=32/21 5=30/22 6=27/22;Final drive|Chain 520, Front sprocket 16, Rear sprocket 41;Clutch|Hydraulically controlled slipper and self-servo wet multiplate clutch. Self bleeding master cylinder.
#####Frame|Aluminium alloy "Front Frame" with optimised stiffnesses;Front suspension|Fully adjustable Showa BPF fork, 43 mm chromed inner tubes;Front Wheel|5-spokes light alloy 3.50" x 17";Front Tyre|Pirelli Diablo Supercorsa SP-V4 120/70 ZR17;Rear suspension|Fully adjustable Sachs unit. Aluminium Hollow Symmetrical Swingarm;Rear Wheel|5-spokes light alloy 6.00” x 17”;Rear Tyre|Pirelli Diablo Supercorsa SP-V4 200/60 ZR17;Wheel Travel (Front/Rear)|125 mm (4.9 in) - 130 mm (5.1 in);Front Brake|2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Hypure® 4-piston calipers with Race eCBS. Self bleeding master cylinder.;Rear Brake|245 mm disc, 2-piston caliper with Race eCBS;Instrumentation|Digital unit with 6,9" TFT display and Optical Bonding, 1,280 x 480 px resolution
#####Wet weight no fuel|191 kg (421 lb);Seat Height|850 mm (33.5 in);Wheelbase|1,485 mm (58.5 in);Rake|24°;Trail|98 mm (3.86 in);Fuel Tank Capacity|17 l - 4.49 gallon (US);Number of Seats|Single seat<br />Two seats, if passenger seat kit accessory is mounted
#####Safety Equipment|Riding Modes, Power Modes, Race eCBS, Ducati Vehicle Observer (DVO), Ducati Traction Control (DTC) DVO, Ducati Wheelie Control (DWC) DVO, Ducati Slide Control (DSC), Engine Brake Control (EBC), Ducati Brake Light (DBL), Chain guard;Standard Equipment|Ducati Power Launch (DPL) DVO, Ducati Quick Shift (DQS) up/down 2.0, Full LED headlights with Daytime Running Light (DRL), Sachs steering damper, Quick adjustment buttons, Pit Limiter, Auto-off indicators;Ready for|Ducati Data Logger (DDL), Anti-Theft, Cruise Control, Tyre Pressure Monitoring System (TPMS), USB port*, Ducati Multimedia System (DMS)*, "Turn By Turn" navigator*<br />*: Please refer to your local dealer for availability
#####Warranty|24 months unlimited mileage;Valve Clearance Check|24,000 km (15,000 miles);Annual Service|12 months;Oil Service|12,000 km (7,500 miles) / 24 months
#####Notes|Bike specifications and equipment may vary from market to market. Please refer to your local dealer for further information
